BlueSolar PWM-Light 12/24V-5A Solar Charge Controller |

Description

Max 60Wp Solar Panel for a 12V Battery System or Max 120Wp Solar Panel for 24V Battery System.

Load output with low battery voltage disconnect function.
Lighting control function, one timer only.
Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.
Three stage battery charging (bulk, absorption, float), not programmable.
Load output protected against over load and short circuit.
Protected against reverse polarity connection of the solar array and/or battery.
Day/night timing options. See manual for details

Battery Voltage: 12/24 V with automatic system voltage detection
Rated charge current: 5A
Automatic load disconnect: Yes
Maximum solar voltage: 28V / 55V (1)
Self-consumption: < 10 mA
Load output: Manual control + low voltage disconnect
Protection: Battery reverse polarity (fuse), Output short circuit, Over temperature

Overload protection
Shut down: after 60 s in case of 130% load
Shut down: after 5 s in case of 160% load
Short circuit: immediate shut down
Grounding: Common positive
Operating temp. range: -20 to +50°C (full load)
Humidity: (non-condensing) Max 95%

BATTERY
Charge voltage ‘absorption’: 14.2V / 28,4V
Charge voltage ‘float’: 13.8V / 27,6V
Low voltage load disconnect: 11,2V / 22,4V
Low voltage load reconnect: 12,6V / 25,2V (manual), 13,1V / 26,2V (automatic)

ENCLOSURE
Protection class: IP20
Terminal size: 5 mm² / AWG10
Weight: 0,15kg
Dimensions: (h x w x d) 70 x 133 x 33,5 mm (2.8 x 5.3 x 1.3 inch)

STANDARDS
Safety: IEC 62109-1
EMC EN 61000-6-1, EN 61000-6-3, ISO 7637-2

For 12V use 36 cell solar panels
For 24V use 72 cell solar panels or 2x 36 cell in series
The controller switches to the lower float voltage level 2 hours after the absorption voltage has been reached. Whenever the battery voltage becomes lower than 13V, a new charge cycle is triggered.
