System Voltage | 12 V |
---|---|
Performance (Pmax) | 110 W |
Generator Performance (Wp) | 110 Wp |
Module Voltage (Vmp) | 18,56 V |
Max. Current (Imp) | 5,97 A |
No-Load Voltage (Voc) | 21,9 V |
Short-Circuit Current (ISC) | 6,34 A |
max (V) | 1000 V |
Cell Type | Monocrystalline |
Degree of Efficiency Cell | >20% |
Tolerance | +/- 3% |
Temperature Coefficient | -0,45%/°C |
Ambient Temperature | -40°C – +85°C |
Solar cells type | Monocrystalline SPR (original Sunpower) |
Solar Module Connection Box | HX-021 |
Connection Box Dimensions | 54 x 107x 0.3 cm |
Connection Box Protection Class | IP67 |
Cable Cross Section | 4.0 mm – 6.0 mm |
Mounting Holes Format | 4 mm |
Number of Cable Entries | 2 |
Bypass Diode | 1 x Shotky |
Lenght of Pre-Installed Cables | 0.8 m |
Pre-assembled Connectors | MC4 |
Shop will be unavailable for next few days. Thank you for your patience and apologize for any inconvenience.
Weight | 2.5 kg |
---|---|
Dimensions | 107.0 × 54.0 × 0.3 cm |
